3D Filament Extruder
Precision benchtop extruder optimized for ABS, PLA, PETG, TPU, and TPE. Perfect for R&D and small-batch filament production with 0.1–3.0 kg/h capacity.
Material Versatility
Optimized for ABS, PLA, PETG, TPU, TPE, and PCL.
Low Waste Efficiency
Requires only 100g of material to start a test run, minimizing experimental waste.
Laboratory Precision
Digital speed control and PID heating up to 350°C for consistent filament quality.
Compact & Quiet
Desktop-friendly design (0.86m length) suitable for office and lab use.
Precision Filament Extrusion in Action
See how the 3D Filament Extruder converts raw pellets into high-quality filament. Watch the precise temperature control and stable extrusion process in a compact lab setting.
- Stable extrusion of PLA and ABS materials.
- Easy-to-use digital control panel.
- Quick material changeovers with minimal waste.
Precision Filament Extrusion for Lab & Light Production
This desktop extruder bridges the gap between experimental research and production. Its 35mm nitrided screw (L/D 13:1) ensures consistent melt quality for engineering plastics, while the precision PID heating system (ambient to 350°C) allows for tight diameter tolerances. The water-cooled feeding zone prevents premature melting, ensuring steady intake even with heat-sensitive materials. Compact and quiet, it fits easily into any office or lab environment.
Nitrided Screw & Barrel
38CrMoAl construction provides exceptional wear resistance for long-term accuracy.
Water-Cooled Feed Zone
Silent water-cooling jacket prevents bridging and ensures consistent material feed.
Schneider & Delixi Components
High-quality electrical components ensure reliable, safe, and long-lasting operation.
Single Phase Power
Standard 220V / 50Hz operation makes it compatible with standard outlets.
Capacity
0.1 - 3.0 kg/h
Screw Diameter
35 mm
L/D Ratio
13:1
Voltage
220V / 50Hz (Single Phase)
Motor Power
400W with Digital Speed Control
Heating Temp
Ambient to 350°C (Precision PID)
Dimensions
0.86m (L) x 0.2m (W) x 0.5m (H)
Weight
~40-50 kg
| Model | Screw Dia (mm) | L/D | Power (W) | Capacity (kg/h) | Dimensions (cm) |
|---|---|---|---|---|---|
| EX-LAB-35 | 35 | 13:1 | 400 | 0.1 - 3.0 | 86 x 20 x 50 |
Lab-Grade Support for Your Research
We understand the importance of precision in research. Our support goes beyond just hardware—we help you optimize your settings for perfect filament results.
1-Year Comprehensive Warranty
Covers all mechanical and electrical components.
Remote Calibration Support
Expert assistance to fine-tune temperature and speed for your specific materials.
Spare Parts Availability
Quick shipping on nozzles, heaters, and screw components.
Custom High-Temp Options
Engage with us for engineering plastic configurations.
Ideal Applications
From material science research to custom filament production.
R&D Testing
Material property testing with minimal sample sizes (100g+).
Filament Production
Small-batch manufacturing of custom colors or compounds.
Education
Teaching polymer processing and 3D printing workflows.
Recycling
Reprocessing shredded 3D prints back into usable filament.
What materials can this extruder handle?
It is optimized for ABS, PLA, PETG, TPU, and TPE. PCL is also supported. High-temp options are available for engineering plastics.
How much material do I need for a test?
The efficient design allows you to start a test run with as little as 100g of material, significantly reducing waste.
Is this suitable for a standard office outlet?
Yes, it operates on single-phase 220V / 50Hz power, making it compatible with standard UK/EU outlets.
What is the output capacity?
The machine produces between 0.1 to 3.0 kg/h, which covers the typical 1-1.5 kg/h requirement for most lab applications.
